The right model depends on more than rated load. A ZLP630 suspended platform, ZLP800 and ZLP1000 may differ in working load, platform layout and overall system requirements. Roof rigging, electrical supply and the route used to deliver materials to the work area can matter as much as the model number.
For a ZLP630 vs ZLP800 vs ZLP1000 comparison, examine complete configurations from the same supplier. Model names alone do not establish interchangeable components or identical specifications across manufacturers. The useful question is which system supports the planned task without adding unnecessary weight, handling or cost.
ZLP630 vs ZLP800 vs ZLP1000 Specifications Compared
IHURMO lists the ZLP630 suspended platform, ZLP800 and ZLP1000 in its aluminum range. The following figures describe the configurations shown on their product pages. They provide a starting point for selection; the confirmed order specification and operating manual govern the supplied equipment.
| Published specification | ZLP630 aluminum | ZLP800 aluminum | ZLP1000 aluminum |
| Rated load | 630 kg | 800 kg | 1,000 kg |
| Platform length | 6 m | 7.5 m | 7.5 m |
| Lifting speed | 9.5 m/min | 9.5 m/min | 8.5 m/min |
| Listed hoist motor power | 2 × 1.5 kW | 2 × 1.8 kW | 2 × 2.2 kW |
Source configurations: IHURMO ZLP630, ZLP800 and ZLP1000.
One useful distinction appears immediately: the listed ZLP800 and ZLP1000 platforms have the same length. Moving to ZLP1000 increases rated load in this comparison, but it does not provide a longer working face. The listed speed is also lower. These differences matter when comparing both material requirements and work cycles.
Compare Rated Load Requirements
Prepare a load schedule before selecting a model. Record personnel, tools, consumables and the largest material batch expected on the platform at the same time. Use the manufacturer’s definition of rated load and account for accessories as its instructions require.
Daily averages can conceal demanding stages. Painting may involve modest material loads, while another stage adds equipment or heavier materials. A platform selected for the lighter stage may not suit the complete project.
For illustration, a planned payload of 700 kg exceeds a 630 kg rating. An 800 kg model may enter the shortlist, but that arithmetic alone does not approve the task. The manufacturer must also check the actual platform configuration, load distribution and intended use. Space, permitted occupancy and material handling remain separate checks.
Avoid using nominal capacity to justify storing surplus materials on one end. An uneven working load can create a different condition from the one covered by the equipment’s load instructions.
Choose the Right Suspended Platform Length
A longer platform can reduce repositioning along a continuous facade. It can also create problems near returns, setbacks, balconies or roof obstacles. The best length follows the building geometry and work sequence.
A six-meter platform may be a useful starting point for shorter facade bays and sites where modules must pass through restricted access routes. A 7.5-meter platform may suit a broader work face when the roof suspension and clearances support that arrangement.
Measure the route used to deliver, assemble and relocate the equipment. A platform that works well once installed may still require excessive dismantling between elevations. Record module dimensions and individual handling weights when repeated moves are expected.
Changes to platform length require the manufacturer’s permitted arrangement. Adding sections or changing suspension positions can affect the system’s allowable load and operating conditions.
ZLP630, ZLP800 and ZLP1000 Applications
ZLP630 Suspended Platform for a Smaller Work Area
Consider ZLP630 when the verified payload fits its rating and the shorter listed platform matches the facade. It can be a sensible candidate for cleaning, painting and maintenance tasks with controlled material quantities. The activity name alone does not establish suitability; the load schedule still decides.
ZLP800 Suspended Platform for More Load and Length
In the listed configurations, ZLP800 adds both capacity and working length compared with ZLP630. This can help where crews need a wider continuous work area or where material quantities exceed the smaller model’s allowance. Compare the benefits with module handling, suspension equipment and total delivery cost.
ZLP1000 Suspended Platform for a Higher Verified Payload
ZLP1000 deserves consideration when the project requires more payload while retaining a similar platform length to ZLP800. Its higher motor rating also makes electrical compatibility part of the comparison. It should not be selected solely because it is the largest option.
Check Roof Rigging and Power Supply Requirements
Send the supplier a roof plan showing parapets, access points, obstructions and proposed suspension locations. The building team must establish whether the proposed supports and load paths suit the structure. Counterweights and suspension assemblies belong to the specified system and arrangement.
For electricity, record voltage, phase, frequency and available supply capacity. Identify the supply point and expected cable route. A matching voltage label is only one part of compatibility; cable selection and the complete electrical arrangement also need review.
These checks often affect the purchase more than a small difference in nominal lifting speed. Discovering an unsuitable roof layout or power arrangement after delivery creates avoidable rework.
Compare Complete ZLP Suspended Platform Quotations
Put each offer into the same format. Confirm platform material and length, hoists, safety locks, suspension equipment, ropes, electrical controls and any specified counterweights. Record rope and cable lengths rather than assuming every package includes the same amount.
Then compare packing, shipping terms, documentation, spare parts and the support included in the price. Separate equipment charges from local installation or inspection services. A lower equipment price may reflect a shorter platform or a narrower supply scope.
Material choice should be assessed separately from model capacity. IHURMO’s suspended platform range includes different material and finish options. Compare equivalent configurations before attributing a weight or cost difference to the model number.
Request a ZLP Model Comparison from IHURMO
Send IHURMO the working height, required platform length, heaviest planned payload, roof drawing and site power details. Request a comparison of the suitable ZLP630, ZLP800 and ZLP1000 configurations, including the complete supply scope. Contact IHURMO to discuss the project and obtain a quotation tied to its actual working conditions.
ZLP Suspended Platform Selection FAQs
Is ZLP1000 always the most productive option?
No. Productivity depends on usable workspace, load requirements, repositioning and the supply of materials. Extra rated capacity offers little benefit when the task is limited by access or installation geometry.
Can parts be shared across ZLP models?
Do not assume interchangeability. Hoists, ropes, safety locks and controls must match the manufacturer’s specified system. A common model family name is not an approval to mix components.
